L’Amira Study Set

From: Original price was: $900.00.Current price is: $500.00.

Right-Reading Reverse - Study Set

** need CAD plans? Contact us at [email protected] **

Description

This product contains a downloadable PDF.

For more information check ‘What’s Included

What's Included

Plan No. MD1904 – l’Amira



STUDY SET: Plan Index

11 sheets printable on 22”x17” format as follow;

p.0 COVER PAGE

p.1 (3) EXTERIOR 3D PERSPECTIVES

p.2 MAIN FLOOR PLAN

p.3 UPPER FLOOR PLAN

p.4 BASEMENT FLOOR PLAN

p.5 FRONT ELEVATION

p.6 LEFT ELEVATION

p.7 BACK ELEVATION

p.8 RIGHT ELEVATION & ROOF PLAN

p.9 BUILDING OUTLINE DIMENSIONS (MAIN FLOOR PLAN)

p.10 BUILDING OUTLINE DIMENSIONS (UPPER FLOOR PLAN)
